General specifications

Product Name:  Eaton Bussmann series high speed square body fuse

Catalog Number:  170M2769

UPC:  051712254502

EAN:  5027590443494

Product Length/Depth:  75 mm

Product Height:  77 mm

Product Width:  163 mm

Product Weight:  228.6 g

Warranty:  Not Applicable

Compliances:  CE Marked
RoHS Compliant

Certifications:  UL Recognized
IEC Rated

Electrical data

Amperage Rating:  315 A

Voltage rating:  690 V (IEC)

Voltage type:  AC

Clearing (I2T):  68500 at 660 V

Pre arc (I2T):  10000

Watt losses:  55 W

Breaking capacity:  200 kA

Class:  Class aR

Product specification

Fuse size:  00

Fitted with::  Type T Indicator for micro
