General specifications

Product Name:  Eaton Bussmann series high speed square body fuse

Catalog Number:  170M5144

UPC:  051712792721

EAN:  5027590455862

Product Length/Depth:  284 mm

Product Height:  67 mm

Product Width:  175 mm

Product Weight:  805.667 g

Warranty:  Not Applicable

Compliances:  CE Marked
RoHS Compliant

Certifications:  UL Recognized
IEC Rated

Electrical data

Amperage Rating:  500 A

Voltage rating:  1250 V (IEC), 1300 V (UL)

Voltage type:  AC

Clearing (I2T):  285000 at 1000 V, 380000 at 1250 V

Pre arc (I2T):  48000

Watt losses:  95 W

Breaking capacity:  100 kA

Class:  Class aR

Product specification

Fuse size:  2
