General specifications

Product Name:  Eaton Bussmann series high speed square body fuse

Catalog Number:  170M5412

UPC:  051712261173

EAN:  5027590457026

Product Length/Depth:  168 mm

Product Height:  80 mm

Product Width:  124 mm

Product Weight:  599.3333333 g

Warranty:  Not Applicable

Compliances:  CE Marked
RoHS Compliant

Certifications:  IEC Rated
UL Recognized

Electrical data

Amperage Rating:  630 A

Voltage rating:  690 V (IEC), 700 V (UL)

Voltage type:  AC

Clearing (I2T):  275000 at 660 V

Pre arc (I2T):  41000

Watt losses:  90 W

Breaking capacity:  200 kA

Class:  Class aR

Product specification

Fuse size:  2
