General specifications

Product Name:  Eaton Bussmann series FWP high speed fuse

Catalog Number:  FWP-350A

UPC:  051712150422

Product Length/Depth:  2.4 in

Product Height:  5.4 in

Product Width:  2.9 in

Product Weight:  1.7 lb

Warranty:  Not Applicable

Compliances:  CE Marked
RoHS Compliant

Certifications:  CSA Certified
UL Recognized

Electrical rating

Amperage Rating:  350A RMS

Interrupt rating:  50 kAIC at 700 Vdc
200 kAIC Vac

Voltage rating:  1400 Vac (FWS 8-15 A), 2100 Vac (FWS 2-6 A), 1000 Vdc (FWL/FWS 2-30 A)

Watt losses:  65 W

Physical details

Packaging type:  Standard

General information

Connection:  Blade end x blade end

Fuse indicator:  Non Indicating

Mounting method:  Stud
