Product Name: Eaton Bussmann series low voltage NH Fuse
Catalog Number: 315NHG2BI
UPC: 051712233323
EAN: 5027590476478
Product Length/Depth: 150 mm
Product Height: 70 mm
Product Width: 53 mm
Product Weight: 671.3333333 g
Compliances: RoHS Compliant
CE Marked
Certifications: IEC 60269-1
IEC 60269-2
DIN 43620
Fuse indicator: Combination fuse status indicator
Interrupt rating: 120 kAIC
Construction: NH2
Construction size: NH2
Insulated metal gripping lugs (IMGL): Yes
No
Quantity: 3
Suitable for: Microswitch 170H0236
EBF Vertical fuse rail
EBV Vertical fuse switch-disconnectors
EBH Size 000 Horizontal fuse switch-disconnectors
Material: Ceramic body
Amperage Rating: 315 A
Frequency rating - max: 62 Hz
Utilization category: gL/gG (cable protection/equipment protection)
Type: fuse
Fitted with:: Metal gripping lugs
Rated switching capacity: 120 kA
Fuse shape: Square body
Knife blade contacts
Breaking capacity: 120 kA
Fuse size: NH000
Frequency rating - min: 45 Hz
Class: Class gG/gL
Voltage rating: 500 V
Application: industrial
Utilities, Solar, Wind
Voltage type: AC
